PostSubject: DC MOTOR DRIVER FOR ROBOTS   Sat Oct 03, 2009 10:55 pm



DC MOTOR DRIVER

Description: when A=low n B =high the motor will move forward n vice versa . To stop the motor either make both A & B high or both low.
for speed controlling in forward direction make one pin B high , n PWM at pin A. more the ON time lesser will be the speed.
Back to top Go down
View user profile http://dragonsoul.darkbb.com
e-bug
Guest



PostSubject: Re: DC MOTOR DRIVER FOR ROBOTS   Sat Sep 04, 2010 1:08 am

afro thanks buddy
